ZONESUN ZS-DLZ420 Automatic Product Vacuum Shrink Packaging Machine
Description
The ZONESUN ZS-DLZ420 is a fully automatic vacuum shrink packaging machine designed for high-efficiency tray forming, vacuum sealing, and shrink wrapping. It integrates bottom film stretching, product loading, vacuum sealing, and shrink tunnel processing into a streamlined system. Operating at 5–7 cycles per minute, it delivers consistent packaging quality with precise temperature and vacuum control. Ideal for food, medical, and industrial applications requiring airtight and shrink-fitted packaging.
Parameter
- Machine Model: ZS-DLZ420
- Operating Efficiency: 5–7 cycles/min
- Forming Temperature: 70–120°C
- Forming Vacuum Pressure: 0.15 MPa
- Sealing Temperature: 125–150°C
- Sealing Pressure: 0.15 MPa
- Forming Time: 1–2 s
- Sealing Time: 1.5–2.5 s
- Final Vacuum Level: ≤200 Pa
- Total Power: Max 10 kW
- Power Supply: 380V / 50Hz
- Frame Material: SUS304 Stainless Steel
- Compressed Air Pressure: ≥0.6 MPa
- Machine Weight: 2000 kg
- Overall Dimensions: 6000 × 1100 × 1860 mm
Description
The ZONESUN ZS-DLZ420 is a fully automatic vacuum shrink packaging machine designed for high-efficiency tray forming, vacuum sealing, and shrink wrapping. It integrates bottom film stretching, product loading, vacuum sealing, and shrink tunnel processing into a streamlined system. Operating at 5–7 cycles per minute, it delivers consistent packaging quality with precise temperature and vacuum control. Ideal for food, medical, and industrial applications requiring airtight and shrink-fitted packaging.
Parameter
- Machine Model: ZS-DLZ420
- Operating Efficiency: 5–7 cycles/min
- Forming Temperature: 70–120°C
- Forming Vacuum Pressure: 0.15 MPa
- Sealing Temperature: 125–150°C
- Sealing Pressure: 0.15 MPa
- Forming Time: 1–2 s
- Sealing Time: 1.5–2.5 s
- Final Vacuum Level: ≤200 Pa
- Total Power: Max 10 kW
- Power Supply: 380V / 50Hz
- Frame Material: SUS304 Stainless Steel
- Compressed Air Pressure: ≥0.6 MPa
- Machine Weight: 2000 kg
- Overall Dimensions: 6000 × 1100 × 1860 mm
Original: $55,000.00
-70%$55,000.00
$16,500.00Description
Description
The ZONESUN ZS-DLZ420 is a fully automatic vacuum shrink packaging machine designed for high-efficiency tray forming, vacuum sealing, and shrink wrapping. It integrates bottom film stretching, product loading, vacuum sealing, and shrink tunnel processing into a streamlined system. Operating at 5–7 cycles per minute, it delivers consistent packaging quality with precise temperature and vacuum control. Ideal for food, medical, and industrial applications requiring airtight and shrink-fitted packaging.
Parameter
- Machine Model: ZS-DLZ420
- Operating Efficiency: 5–7 cycles/min
- Forming Temperature: 70–120°C
- Forming Vacuum Pressure: 0.15 MPa
- Sealing Temperature: 125–150°C
- Sealing Pressure: 0.15 MPa
- Forming Time: 1–2 s
- Sealing Time: 1.5–2.5 s
- Final Vacuum Level: ≤200 Pa
- Total Power: Max 10 kW
- Power Supply: 380V / 50Hz
- Frame Material: SUS304 Stainless Steel
- Compressed Air Pressure: ≥0.6 MPa
- Machine Weight: 2000 kg
- Overall Dimensions: 6000 × 1100 × 1860 mm
