The ZS-VTMP6D is a fully automatic liquid filling machine equipped with six diving nozzles and a magnetic pump system. Designed for skincare, cosmetics, and daily chemical products, it features a PLC touchscreen for easy volume control and a conveyor belt for continuous bottle feeding. Ideal for improving production efficiency with precise and hygienic filling.

Parameter

• Machine model:ZS-VTMP6D
• Voltage:110/220V 50-60HZ 1350W
• Max flow rate:6000ml/min
• Filling pump:Magnetic pump
• Working speed:About 12-30 bottles/min
• Filling range:5-3000ml(recommend)
• Filling nozzle size:OD6 & 8 mm
• Suitable bottle height:About 5-40cm
• Suitable bottle diameter:≤100mm
• Package size:About 1990*560*540mm+720*560*380mm
• Package weight:About 118kg+42kg

Quantitative filling, operator can enter certain number by control panel to set filling volume.This is more convenient to debug and operate the machine.

The quantity of filling nozzles can be customized as production need.Working height can be adjusted according to bottle size.

Equipped with 316 stainless steel magnetic pump. It is suitable for the weakly corrosive liquid, this kind of filling pump has higher filling accuracy, it is the ideal choice for filling low viscosity liquid

The electric eye can detect passing by bottles and send signal to the system to control machines work automatically. The sensitivity of electric eye can be adjusted as production need and improves working accuracy.

With chain conveyor, this has larger weight capacity, and can convey product smoothly.The width of conveyor can be customized as production need
