ZONESUN ZS‑CF4 Carbonated Beverage Mixer and 4‑Head Liquid Filler
The ZONESUN ZS‑CF4 is engineered for efficient, precise filling of carbonated drinks such as cola, beer, and soda. Equipped with a mixing tank and a 4‑head isobaric filler, it minimizes foam and preserves carbonation for superior product quality. Ideal for beverage producers seeking reliable performance in small to medium‑scale production, it ensures smooth, consistent bottling with reduced waste.
Filler
Parameter Details
Filling Nozzle Quantity 4
Working Temperature 4 – 10 °C
Working Capacity 300 – 500 BPH
Inlet & Outlet Diameter 32 mm
Air Pressure 0.5 – 0.7 MPa
Machine Size Approx. 1090 × 590 × 1800 mm
Mixer
Parameter Details
Production Capacity 1.5 – 2 t/h
Mixing Ratio (Syrup : Water) 1 : 2 – 1 : 8
Beverage Liquid Outlet Temperature < 6 °C
Beverage Liquid Outlet Pressure 0.3 – 0.5 MPa
Carbonation Gas Content 3 G.V.
The ZONESUN ZS‑CF4 is engineered for efficient, precise filling of carbonated drinks such as cola, beer, and soda. Equipped with a mixing tank and a 4‑head isobaric filler, it minimizes foam and preserves carbonation for superior product quality. Ideal for beverage producers seeking reliable performance in small to medium‑scale production, it ensures smooth, consistent bottling with reduced waste.
Filler
Parameter Details
Filling Nozzle Quantity 4
Working Temperature 4 – 10 °C
Working Capacity 300 – 500 BPH
Inlet & Outlet Diameter 32 mm
Air Pressure 0.5 – 0.7 MPa
Machine Size Approx. 1090 × 590 × 1800 mm
Mixer
Parameter Details
Production Capacity 1.5 – 2 t/h
Mixing Ratio (Syrup : Water) 1 : 2 – 1 : 8
Beverage Liquid Outlet Temperature < 6 °C
Beverage Liquid Outlet Pressure 0.3 – 0.5 MPa
Carbonation Gas Content 3 G.V.
Original: $4,500.00
-70%$4,500.00
$1,350.00Description
The ZONESUN ZS‑CF4 is engineered for efficient, precise filling of carbonated drinks such as cola, beer, and soda. Equipped with a mixing tank and a 4‑head isobaric filler, it minimizes foam and preserves carbonation for superior product quality. Ideal for beverage producers seeking reliable performance in small to medium‑scale production, it ensures smooth, consistent bottling with reduced waste.
Filler
Parameter Details
Filling Nozzle Quantity 4
Working Temperature 4 – 10 °C
Working Capacity 300 – 500 BPH
Inlet & Outlet Diameter 32 mm
Air Pressure 0.5 – 0.7 MPa
Machine Size Approx. 1090 × 590 × 1800 mm
Mixer
Parameter Details
Production Capacity 1.5 – 2 t/h
Mixing Ratio (Syrup : Water) 1 : 2 – 1 : 8
Beverage Liquid Outlet Temperature < 6 °C
Beverage Liquid Outlet Pressure 0.3 – 0.5 MPa
Carbonation Gas Content 3 G.V.
