ZONESUN ZS-FAL180R9/ZS-DPCL1 Custom Liquid & Paste Filling Capping Labeling Line Set
ZONESUN offers two complete packaging lines tailored for different production needs. The ZS-FAL180R9 line features heated piston filling for liquids and pastes, while the ZS-DPCL1 line uses diaphragm pumps for high-speed liquid filling. Both systems integrate precise capping and labeling modules, delivering reliable performance for small to medium-scale manufacturing. Whether you're bottling sauces, oils, or cosmetics, ZONESUN provides a turnkey solution to streamline your workflow.
Parameter Details
Model ZS-YT4T-4PX Filling Machine
Voltage 110/220V, 50–60Hz, 1KW
Filling Range 10–180 ml / 30–500 ml / 100–1000 ml
Working Speed Approx. 30–100 bottles per minute
Air Pressure 0.6–0.8 MPa
Filling Nozzles 4 (customizable)
Heating Temperature Approx. 30–90°C
Mixing Speed Approx. 5–50 rpm
Machine Dimensions Approx. 2000 × 800 × 1800 mm (L × W × H)
Model ZS-VTDP12P Filling Machine
Voltage 220V / 110V, 50–60Hz, 700W
Filling Range (per pump) 30–4000 ml
Working Speed Approx. 10–40 bottles/min (depends on liquid & bottle size)
Max Suction Distance 1.5 meters
Max Flow Rate (per pump) 4L/min ±2%
Filling Nozzle OD 6 mm
Conveyor Size Approx. 114 × 1900 mm (W × L)
Machine Weight Approx. 131 kg
Machine Dimensions Filling Unit: Approx. 500 × 250 × 580 mm
Conveyor: Approx. 1900 × 380 × 1600 mm
Bracket: Approx. 520 × 520 × 770 mm
Specification ZS-XG16E ZS-XG16 Capping Machine
Bottle Height 30–300 mm 30–300 mm
Cap Diameter 18–70 mm 18–70 mm
Bottle Diameter 20–160 mm 20–160 mm
Working Speed 20–60 bottles/min Varies by bottle and cap size
Working Voltage AC 220V / 110V, 50–60Hz AC 220V / 110V, 50–60Hz
Working Pressure 0.4–0.6 MPa 0.4–0.6 MPa
Machine Size (L×W×H) Approx. 1930 × 740 × 1600 mm Approx. 2000 × 820 × 1760 mm
Net/Gross Weight Approx. 150 kg / 334 kg Approx. 113 kg / 192 kg
Model ZS-TB260R Labeling Machine
Power Supply AC 220V, 50/60Hz, 1000W
Labeling Capacity 25–50 bottles/min (depends on bottle size)
Suitable Bottle Diameter Ø12–100 mm
Label Size Length: 20–300 mm <br> Height: 15–150 mm
Roll Inner Diameter Ø76 mm
Roll Outer Diameter Ø250 mm
Conveyor Size 112 × 2000 mm
Machine Dimensions (L×W×H) Approx. 2000 × 820 × 1380 mm
Packing Dimensions (L×W×H) Approx. 2000 × 820 × 1380 mm
Net/Gross Weight Approx. 180 kg / 250 kg
