ZONESUN ZS‑YTCP12V Semi‑Automatic Pneumatic Syringe Filling Machine
The ZONESUN ZS‑YTCP12V Pneumatic Syringe Filling Machine is a semi‑automatic unit equipped with a high‑precision ceramic plunger pump for accurate dosing of liquids and pastes. Designed for syringe filling, it achieves an accuracy of ≤ ±0.5 %, making it ideal for applications in cosmetics and medical industries. With multiple filling range options (1–12 ml, 2–25 ml, 5–50 ml), stainless steel construction, and a 20 L hopper, this compact and durable machine delivers consistent performance for small to medium‑scale production.
ZS‑YTCP12V — Specifications
Parameter Details
Machine Model ZS‑YTCP12V
Machine Pump Ceramic plunger pump
Voltage 110 V / 220 V, 50‑60 Hz
Filling Range 1 – 12 ml / 2 – 25 ml / 5 – 50 ml
Working Speed 0 – 60 pieces/min (based on liquid & volume)
Air Pressure 0.4 – 0.6 MPa
Hopper Size 20 L
Filling Accuracy ≤ ±0.5 %
Machine Material Stainless steel
Machine Size Approx. 325 × 325 × 1050 mm
Machine Weight Approx. 24 kg
The ZONESUN ZS‑YTCP12V Pneumatic Syringe Filling Machine is a semi‑automatic unit equipped with a high‑precision ceramic plunger pump for accurate dosing of liquids and pastes. Designed for syringe filling, it achieves an accuracy of ≤ ±0.5 %, making it ideal for applications in cosmetics and medical industries. With multiple filling range options (1–12 ml, 2–25 ml, 5–50 ml), stainless steel construction, and a 20 L hopper, this compact and durable machine delivers consistent performance for small to medium‑scale production.
ZS‑YTCP12V — Specifications
Parameter Details
Machine Model ZS‑YTCP12V
Machine Pump Ceramic plunger pump
Voltage 110 V / 220 V, 50‑60 Hz
Filling Range 1 – 12 ml / 2 – 25 ml / 5 – 50 ml
Working Speed 0 – 60 pieces/min (based on liquid & volume)
Air Pressure 0.4 – 0.6 MPa
Hopper Size 20 L
Filling Accuracy ≤ ±0.5 %
Machine Material Stainless steel
Machine Size Approx. 325 × 325 × 1050 mm
Machine Weight Approx. 24 kg
Original: $2,680.00
-70%$2,680.00
$804.00Description
The ZONESUN ZS‑YTCP12V Pneumatic Syringe Filling Machine is a semi‑automatic unit equipped with a high‑precision ceramic plunger pump for accurate dosing of liquids and pastes. Designed for syringe filling, it achieves an accuracy of ≤ ±0.5 %, making it ideal for applications in cosmetics and medical industries. With multiple filling range options (1–12 ml, 2–25 ml, 5–50 ml), stainless steel construction, and a 20 L hopper, this compact and durable machine delivers consistent performance for small to medium‑scale production.
ZS‑YTCP12V — Specifications
Parameter Details
Machine Model ZS‑YTCP12V
Machine Pump Ceramic plunger pump
Voltage 110 V / 220 V, 50‑60 Hz
Filling Range 1 – 12 ml / 2 – 25 ml / 5 – 50 ml
Working Speed 0 – 60 pieces/min (based on liquid & volume)
Air Pressure 0.4 – 0.6 MPa
Hopper Size 20 L
Filling Accuracy ≤ ±0.5 %
Machine Material Stainless steel
Machine Size Approx. 325 × 325 × 1050 mm
Machine Weight Approx. 24 kg
