ZONESUN ZS-MD210 High-Speed Industrial Checkweigher Machine
The ZS-MD210 checkweigher delivers fast, precise weight inspection for bags, bottles, cartons, and cases. Designed for seamless integration into automated packaging lines, it ensures consistent quality control with minimal operator effort. Ideal for industries requiring high throughput and reliable performance.
ATTENTION
This machine comes with the 220V model only. If you select the 110V option, we will send a 220V one and an extra transformer for use.
Parameter
Power Supply AC 220V ±10%, 50/60Hz
Rated Power 0.15 KW
Weighing Range 1g – 1500g
Accuracy ±1g
Minimum Scale 0.1g
Conveying Speed 10–30 m/min
Max Throughput Up to 160 pcs/min
Conveyor Size (Max) ≤300 × 200 mm
Conveyor Size (Standard) Approx. 210 × 210 mm
Rejection Type Push / Lever / Flap / Air Blower / Belt Sinking (Customizable)
Weighing Technology EMFR Load Cell
Throughput Direction Left to right (facing control panel)
Air Supply 0.6–1 MPa
Air Connector Size Φ8 mm
Body Material SUS304 Stainless Steel
Working Environment Temperature: -30°C to +40°C<br>Humidity: 30% to 95%
Machine Dimensions (L×W×H) Approx. 1522 × 720 × 1222 mm
Package Dimensions (L×W×H) Approx. 1303 × 960 × 1250 mm
Machine Weight Approx. 174 kg
The ZS-MD210 checkweigher delivers fast, precise weight inspection for bags, bottles, cartons, and cases. Designed for seamless integration into automated packaging lines, it ensures consistent quality control with minimal operator effort. Ideal for industries requiring high throughput and reliable performance.
ATTENTION
This machine comes with the 220V model only. If you select the 110V option, we will send a 220V one and an extra transformer for use.
Parameter
Power Supply AC 220V ±10%, 50/60Hz
Rated Power 0.15 KW
Weighing Range 1g – 1500g
Accuracy ±1g
Minimum Scale 0.1g
Conveying Speed 10–30 m/min
Max Throughput Up to 160 pcs/min
Conveyor Size (Max) ≤300 × 200 mm
Conveyor Size (Standard) Approx. 210 × 210 mm
Rejection Type Push / Lever / Flap / Air Blower / Belt Sinking (Customizable)
Weighing Technology EMFR Load Cell
Throughput Direction Left to right (facing control panel)
Air Supply 0.6–1 MPa
Air Connector Size Φ8 mm
Body Material SUS304 Stainless Steel
Working Environment Temperature: -30°C to +40°C<br>Humidity: 30% to 95%
Machine Dimensions (L×W×H) Approx. 1522 × 720 × 1222 mm
Package Dimensions (L×W×H) Approx. 1303 × 960 × 1250 mm
Machine Weight Approx. 174 kg
Original: $3,899.00
-70%$3,899.00
$1,169.70Description
The ZS-MD210 checkweigher delivers fast, precise weight inspection for bags, bottles, cartons, and cases. Designed for seamless integration into automated packaging lines, it ensures consistent quality control with minimal operator effort. Ideal for industries requiring high throughput and reliable performance.
ATTENTION
This machine comes with the 220V model only. If you select the 110V option, we will send a 220V one and an extra transformer for use.
Parameter
Power Supply AC 220V ±10%, 50/60Hz
Rated Power 0.15 KW
Weighing Range 1g – 1500g
Accuracy ±1g
Minimum Scale 0.1g
Conveying Speed 10–30 m/min
Max Throughput Up to 160 pcs/min
Conveyor Size (Max) ≤300 × 200 mm
Conveyor Size (Standard) Approx. 210 × 210 mm
Rejection Type Push / Lever / Flap / Air Blower / Belt Sinking (Customizable)
Weighing Technology EMFR Load Cell
Throughput Direction Left to right (facing control panel)
Air Supply 0.6–1 MPa
Air Connector Size Φ8 mm
Body Material SUS304 Stainless Steel
Working Environment Temperature: -30°C to +40°C<br>Humidity: 30% to 95%
Machine Dimensions (L×W×H) Approx. 1522 × 720 × 1222 mm
Package Dimensions (L×W×H) Approx. 1303 × 960 × 1250 mm
Machine Weight Approx. 174 kg
