ZONESUN ZS‑GTJ Pneumatic Paste Filling Machine with Mixer and Hopper
The ZONESUN ZS‑GTJ Pneumatic Paste Filling Machine with Mixer is built for precision, hygiene, and versatility in filling operations. Featuring a rugged rotary valve design, food‑grade stainless steel contact parts, and a large 30L hopper, it ensures smooth, no‑drip dispensing for a wide range of viscosities. The pneumatic system, adjustable piston feed, and intuitive control panel make operation effortless, while quick‑disconnect fittings simplify cleaning and maintenance. Customizable options such as heated hoppers, larger capacity, or additional filling heads allow this machine to adapt to diverse production requirements in food, cosmetics, chemical, and pharmaceutical industries.
PARAMETER
- Model：ZS-GTJ
- Type：Paste Filling Machine
- Filling Nozzle：Single Nozzle (Double Nozzle Optional)
- Filling Speed：5–25 bottles/min
- Filling Range：10-100ml/10-200ml/30-300ml/50-500ml/100-1000ml/500-2500ml/1000-5000ml
- Rotation Speed：0–1700 r/min
- Filling Accuracy：≤ ±0.5% – 2%
- Air Pressure：0.4–0.6 MPa
- Air Tank Capacity：＞30 L
- Machine Size (L×W×H)：773 × 280 × 910 mm
- Packing Size：930 × 360 × 335 mm (Machine)440 × 455 × 505 mm (Hopper)
- Net Weight：34.5 kg
- Gross Weight：25 kg (Machine)14.5 kg (Hopper)
The ZONESUN ZS‑GTJ Pneumatic Paste Filling Machine with Mixer is built for precision, hygiene, and versatility in filling operations. Featuring a rugged rotary valve design, food‑grade stainless steel contact parts, and a large 30L hopper, it ensures smooth, no‑drip dispensing for a wide range of viscosities. The pneumatic system, adjustable piston feed, and intuitive control panel make operation effortless, while quick‑disconnect fittings simplify cleaning and maintenance. Customizable options such as heated hoppers, larger capacity, or additional filling heads allow this machine to adapt to diverse production requirements in food, cosmetics, chemical, and pharmaceutical industries.
PARAMETER
- Model：ZS-GTJ
- Type：Paste Filling Machine
- Filling Nozzle：Single Nozzle (Double Nozzle Optional)
- Filling Speed：5–25 bottles/min
- Filling Range：10-100ml/10-200ml/30-300ml/50-500ml/100-1000ml/500-2500ml/1000-5000ml
- Rotation Speed：0–1700 r/min
- Filling Accuracy：≤ ±0.5% – 2%
- Air Pressure：0.4–0.6 MPa
- Air Tank Capacity：＞30 L
- Machine Size (L×W×H)：773 × 280 × 910 mm
- Packing Size：930 × 360 × 335 mm (Machine)440 × 455 × 505 mm (Hopper)
- Net Weight：34.5 kg
- Gross Weight：25 kg (Machine)14.5 kg (Hopper)
Original: $85.00
-70%$85.00
$25.50Description
The ZONESUN ZS‑GTJ Pneumatic Paste Filling Machine with Mixer is built for precision, hygiene, and versatility in filling operations. Featuring a rugged rotary valve design, food‑grade stainless steel contact parts, and a large 30L hopper, it ensures smooth, no‑drip dispensing for a wide range of viscosities. The pneumatic system, adjustable piston feed, and intuitive control panel make operation effortless, while quick‑disconnect fittings simplify cleaning and maintenance. Customizable options such as heated hoppers, larger capacity, or additional filling heads allow this machine to adapt to diverse production requirements in food, cosmetics, chemical, and pharmaceutical industries.
PARAMETER
- Model：ZS-GTJ
- Type：Paste Filling Machine
- Filling Nozzle：Single Nozzle (Double Nozzle Optional)
- Filling Speed：5–25 bottles/min
- Filling Range：10-100ml/10-200ml/30-300ml/50-500ml/100-1000ml/500-2500ml/1000-5000ml
- Rotation Speed：0–1700 r/min
- Filling Accuracy：≤ ±0.5% – 2%
- Air Pressure：0.4–0.6 MPa
- Air Tank Capacity：＞30 L
- Machine Size (L×W×H)：773 × 280 × 910 mm
- Packing Size：930 × 360 × 335 mm (Machine)440 × 455 × 505 mm (Hopper)
- Net Weight：34.5 kg
- Gross Weight：25 kg (Machine)14.5 kg (Hopper)
