DESCRIPTION

The ZS-CPL is a fully automated horizontal case packer engineered for continuous, high-efficiency operation. It integrates servo and pneumatic motion control to erect, load, and seal cartons in one streamlined process. Compatible with various case types—including RSC, HSC, trays, and wraparound—it offers unmatched flexibility for evolving packaging needs. Ideal for bottling lines and canned goods, this machine is custom-built to match your product specifications.

PARAMETER

Model：ZS-CPL
Power supply：3Phase,220v/380v,50/60HZ,5kw
Air pressure：6kg/cm2, 450ml/min
Machine size：5500-7500*1600*2500mm
Suitable bottle type：All kinds of bottles/cans
Packing speed：9-12 cartons/min
Feeding bottle height：1100mm±50mm
Grab quantity：3-6 sets
Weight：200kg

ATTENTION

• This is a fully custom machine, which means we need the information about your products.

• The parameter varies for different products.

• All images are for illustration purposes only and actual products may vary due to product enhancement or change.
